FEATURES :
LEGENDARY MAYTAG DEPENDABILITY
Maximizing your equipment investment for over a half-century.
FOR YOUR CUSTOMERS:
• Extra Large 7.4-Cu.-Ft. Capacity
• Simple Controls Are Easy for Multiple Users
• Powerful, High Airflow Dries Load Quickly,Saving Time
• Extra-Large Door and Drum Openings Allow Quick, Easy Loading and Unloading
FOR YOUR OPERATION:
• TurboVent™Technology Provides Faster Drying and Better Performance on Long Vents
• 4-Way Venting—Right or Left Side, Back or Front
• Accepts a Variety of Slides
• Large-Capacity Metal Mesh Lint Filter
• Front Access for Easier Self-Service
• Reversible Side-Swing Door
BUILT-TO-L AST™FEATURES:
• Premium Porcelain-Enamel Top
• Four-Roller Suspension with Permanently Lubricated Bearings
• Blower Guard Reduces Service Calls
• High-Security Vault
• 5-Year Limited Warranty—All Parts Covered
DRYER SPECIFICATIONS
MODEL MDG18PR
MOTOR
Single-phase, thermoprotected against overload, auto-reset
HP (kw). 33 (.25)
TUMBLE SPEED—RPM 50 ± 1
CAPACITY
Cu. ft. (liters) 7. 4 (210)
AIRFLOW
Gas models—cfm (cmm) 230(6.5)
Electric models—cfm (cmm) 215 (6 .1)
SOUND LEVEL (EXPORT ODEL ONLY)
Sound pressure level, Lpa (BA) (Kpa: ± 10dBA) 58
TUMBLE SPEED
RPM 50 1
ELECTRICAL REQUIREMENTS
MdE model—voltage 240 V/60Hz*
MDG model—voltage 120V/60Hz
BREAKER/FUSE REQUIREMENTS—amps
MDE model 30
MDG model 15
MDE export model 25
MDG export model 10
ELECTRIC HEATING ELEMENT—watts
Domestic models 5,600
Canadian models 5,250EXHAUST DUCT DIAMETER
In. (mm) 4 (101.6)* *
ELECTRONIC BURNER IGNITION
MDG model •
GAS RATING
MDG model—BTU/hr. (kcal/hr.) 24,000 (6,048)AUTOMATIC PRESSURE REGULATOR
MDG model •
ADJUSTABLE LEVELING LEGS •
APPROXIMATE WEIGHT
Crated—lbs. (kg) 140 (63,5)
Uncrated—lbs. (kg) 126 (57,2)
DIMENSIONS
Width—in. (mm) 27 (686)
Depth—in. (mm) 29 (737)
Height—in. (mm) 41(1,040)
